M210L Alloy Wheel Lathe

The Lenco M210/L Alloy Wheel Lathe is a proven cnc lathe for Alloy Wheel Machining, with its small foot print and wide box type bed construction providing increased Rigidity and stability, coupled with its unique custom cycle digitizing and programming direct to a cam profile it is probably one of the smallest and most reliable machines to date.
The M210/L is as truer thoroughbred as our larger models designed and built to last, with a full oil bath head stock spindle housing and automatic lubrication system fitted as standard the construction is in keeping with our larger more expensive stable mates.

Description

M210L Alloy Wheel Lathe

Over the past few years, we have dedicated ourselves to pursue higher technological levels and strived to provide a number high-quality lathe models that will not only provide years of dependable performance but that will meet and exceed the market demand for the years to come.
In addition, we have enhanced and expanded our research and development programme to seek improvements which add value.
The M210L has the same construction features as larger lathes but with a lower centre of gravity which in turn reduces the footprint required for stability. Currently able to resurface most Oem derived alloy wheels up to 24 ins in diameter.

Model M210L
WIDTH CAPACITY Swing over the bed (mm) Center Height (mm) Swing over cross slide (mm) Distance between centres (mm) HEAD STOCK Spindle speed (rpm) Spindle bore (mm) Spindle nose MOTOR Spindle motor (HP) Ball screw (Dia x pitch) (mm) Z-Axis drive motor (Nm) X-axis drive motor (Nm) Coolant pump motor (HP) SADDLE Longitudinal travel (Z – axis) (mm) Cross slide travel (X – axis (mm) X/Z FEED Z – axis rapid travel (mm) X – axis rapid travel (mm) MEASUREMENT Machine weight Floor space (L x W x H ) Machine size (L x W x H )
600 300 400 800 AUTOMATIC 1200 85 10 X:25 x 5 / Z:40 x 10 6.3 6.3 1/6 680 400 7 M/min 5 M/min 3200 2300 x 1760 x 1910 2100 x 1420 x 1820

4 position electrical tool turret
MPG hand wheel
Headstock and oil cooler
15 hp spindle motor
Chip tray / conveyor rim

All castings are made of high tensile meehanite cast iron eliminating internal residual stress. Spindle & Gears are constructed from CR-MO alloy steel and precisely ground.
AC main spindle motors
Inverter controlled spindle drive, delivering constant spindle speed (C.S.S) in combination with automatic cross feed delivers greater cutting accuracy and efficiency for facing work associated with the cutting of alloy wheels.
Inverter controlled spindle braking
Automatic lubrication system fitted as standard for extended service life. Oil bath headstock spindle for longer life expectancy.
Wide bed construction carefully designed for maximum stability and increased rigidity whist retaining a small foot print.





Model M 210S
Operating Controller 10 HP Spindle Motor Quick change Tool Post 15 ins 3 jaw chuck with soft jaws Automatic lubrication system Coolant system and pump Digitizing probe Volateg 400V/3PH/50HZ

Foot print dimensions:
The actual Machine dimensional sizes are shown opposite, we recommend that an 800mm access clearance is maintained around the machine to the rear, right and left hand side. This will give a footprint of width 3500mm depth 2700mm.
The minimum clearance for the access doors to open is 3500 mm width and 2250 mm depth.
Foundation requirement:
A solid concrete floor slab, measuring no less than 150 mm In thickness not to include hard-core.
