Principle of operation
Powder coat application takes place the spray booth in an electrostatic environment. The powder booth sucks air along with the powder by a fan into the arrestor filters in front of the operator. The air is then filtered and passed back into the atmosphere of the working environment. The filters are cleaned separately using a unique nozzle which cleans the complete filter. The booth filters 99.98% of particles above 2 micron’s.
The spray cabin is constructed of mild steel which has been folded and welded prior to being powder coated and assembled.
PLC Controller – 4″ touch panel*
3 Work modes*
Automatic – filter clog sensor, Automatic – time depending, manual*
Prepared for installing anti-explosion system as required EN 50177:2009*
Built in pneumatic air tank
individual filter cleanse
Thickness of the filter material as in automatic lines – filters do not require replacement (260g/m2)
Doubled filter surface area relative to the competition
Manual powder recovery
Automatic cleaning (PCB, Swiss)
Cleaning of filters with specially developed JET nozzle (Swiss)
Synthetic filter material with high-efficiency separation of dust, water resistant
The possibility of setting the interval between filter cleaning
* Excluding KPZ-2 model Booth
Hopper for waste powder
Hopper with sieve, fluidisation and powder return
External sieve with hopper (490EUR + VAT)
Power and Installation Requirements
Standard Features and Fitment
Dimensions 750 width x 1360 height x 880 depth.
External dimensions 1200 width x 2200 height x 1600 depth
Filter amount 2 pcs. 100% Polyester, filtration area 20 m2!
Electric data 0,69 kW x1pcs. 380V 50-60Hz
Filtration efficiency 99,9%
Cleaning filter system AutoJet
Used metal type DC 01
Aluminium fan 5,100m3/h x1pcs.
Powder hopper No
Floor Standard, not lowered
